Circuit Breaker 2 Pole 6kA 20A

Circuit Breaker 2 Pole 6kA 20A

$13.27 ex. GST

C Curve
36mm Width
FUSION Series
Product Code: MCB2620C
Warranty: 5 Year InHouse
Bulk Quantity Discounts
1-56+
$13.27 ex. GST$12.64 ex. GST
SKU: MCB2620C Categories: , , , Tags: , ,

Description

This is the FUSION Series 20A 2 Pole MCB in 6kA C Curve! The FUSION Series range of circuit protection devices have been made from the highest grade components. This is to ensure reliability in all applications where protection against overload and short circuit is required. Because of this, all of our miniature circuit breakers comply with AS/NZS 60898.1 and AS/NZS 60947.2.

The 6kA breaking capacity of our 20A 2 Pole MCB makes it the perfect choice in commercial and industrial applications!

The features for our 6kA miniature circuit breakers include 18mm pole width and ON/OFF indicators. They will take up to 25mm2 cable, 35mm DIN rail mounting and have lockable toggles. It also has a pin/fork type busbar terminal connection. These 6kA miniature circuit breakers are available in 1-3 pole, 6 to 63amps, C and D Curve.

As with all of our products, this product comes with a 5 Year In House Warranty. That’s right, 5 years! This is so that you can have peace of mind knowing that if a fault arises within a five year period, we will cover the cost of replacing the product and it’s installation by an authorised electrician. In other words, we’ve got your back. Check out our online Warranty Policy for all terms and conditions, otherwise you can view it here!

Product Code

MCB2620C

Related Products

DBSMC12, MS363, RCD21040, LN10, DBBF, HRC80

Series

FUSION Series

Volts

240V/415V AC

Amps

20A

Power

6kA

Poles

2 Pole

Configuration

C Curve

Colour

Grey

Compliance
  • AS/NZS 60898.1:2004
Approval

Energy Safe Victoria

Features
  • 18mm Width Per Pole
  • ON/OFF Indicators
  • 35mm DIN Rail Mounting
  • Available in C and D Curve
  • Lockable Toggle
  • Combination Head Screws
  • Pin/Fork Type Busbar Terminal Connection
Downloadable PDFs

MCBs.pdf
MCB Data Sheet

MCB Data Sheet
